• 一般规格

         型号：                                of20lp30                        of2lp 100                    of 2lp200

         标准阻值范围：                  100ω~ 10kω                     100ω~2kω                    100ω~5kω

         最大可选阻值：                        2kω                                4kω                              8kω

         总阻公差：                                                                 标准级±5%（j)

                                                                                            精密级±3%（h)

         独立线性公差：标准级               ± 0.7%                                               ±0.5%

                                  精密级               ±0. 4                                               ±0.25%

         功率：                                        0.75w                              1.0w                                 2.0w

         信噪：                                                                        ＜100ωe.n.r.

        电气行程：                                 5±1mm                         100±1mm                           200±1mm

        机械行程：                                 约53mm                         约103mm                            约203mm

        绝缘电阻：                                                              ＞100mω（500v.d.c.)

        介质耐压：                                                                1分钟（90v.a.c.)

        摩擦力：                                                                        ＜15n(1500gf)（1.5kgf）

        停止耐压：                                                                   约90n（9kgf)

        电阻温度系数：                                                            ±20p.p.m./°c

        质量：                                         约100g                           约150g                                 约180g

• 可选特殊规格

          1、轴上特殊加工

          2、非注油型

          3、附加接线端（最多附加一个接线端）
